I will show you step by step how to install/upgrade your Front Crossbar and add the Hydra Fan Ducts for the Ender 5 Plus.
=== Chapters ===
0:00 Intro / CrossBar Relocation
3:26 Installing of Hydra Fan Duct
====== CrossBar Relocation ======
Ender 5 Plus front crossbar relocation
https://www.thingiverse.com/thing:4485125
====== HYDRA FAN DUCT ======
Link to all the parts: https://www.thingiverse.com/thing:4062242 Parts I used:
– 5015_LH_V3.stl
– 5015_RH_V3.stl
– Bowden_Cable_Clip.stl
– Rear_Duct_Base_Ender_5_V1_2.stl
– Side_Duct_Base_Ender_5_V1_2.stl
I used this because I have the cable chain (Bowden_Head_withchain_link_bracket.stl) but you can use the flat Bowden only one.
=== BL Touch Fan Mount ===
I attached the fan mount for the BL Touch —
Fan Mounted BLTouch (multiple models including covers)
https://www.thingiverse.com/thing:4617163
=== Fans To Buy ===
You need one — Noctua NF-A4x10 FLX, Premium Quiet Fan, 3-Pin (40x10mm, Brown)
https://amzn.to/35EotGI
You need two — WINSINN 50mm Blower Fan 24V 5015 Dual Ball Bearing 50x15mm Turbine Turbo Brushless – High Speed (Pack of 4Pcs)
https://amzn.to/3IOxPxS
I bought the four-pack in case one burns out – you will need to split and solder in the additional fan (you are going from a 2 fan setup to a three fan setup)
=== Socket Screws to Buy ===
Socket Head Cap Screw M5
https://amzn.to/3ufmlQ6
Socket Head Cap Screw M2 M3 M4
https://amzn.to/3HtpMGg
T Nuts,M3 M4 M5 T Slot Nut Hammer Head Fastener
https://amzn.to/3uhBv7g
Solder and Seal Butt Connectors Kit, Self-Solder Heat Shrink Wire Connectors
https://amzn.to/3s9rOFc
